MODEL NO. | LSGP-002 |
Description | 2.5W/4KW, Parlight,UV Lens |
LAMPS | |
HMI | 2.5KW/4KW 115V/200V G38/G38 |
PERFORMANCE DATA | |
Color temperature | 5600K |
Dimensions | 841Hx520Wx555L(mm) |
N.W. | 25kg |
UV Lens | 347mm UV |
| IP Class | IP23 |
Compliance | CE |
ACCESSORIES | |
Barndoor | 405mm |
Diffuser frame | NONE |
Stand | LS-06 |
Electronic Ballast | EB 2.5KW/4KW |
Extension cable | 7.5m or 15m extension cable with Veam connector |
Illuminance（Lux） | |||||
Distance | 15m | 20m | 25m | Beam angle | |
No Lense | Illuminance | 102500 | 45530 | 25688 | 5° |
Beam Diameter | 0.9m | 1.4m | 1.7m | ||
Spot | Illuminance | 56780 | 25230 | 14188 | 7° |
Beam Diameter | 1.3m | 1.7m | 2.5m | ||
Narrow Flood | Illuminance | 22376 | 9967 | 5570 | 11°x29° |
Beam Diameter | 1.9x3.4m | 2.9x5.2m | 3.9x6.8m | ||
Flood | Illuminance | 7767 | 3488 | 1998 | 19°x39° |
Beam Diameter | 3.3x7.2m | 5.0x10.8m | 6.7x14.5m | ||
Supper Flood | Illuminance | 4022 | 1768 | 1025 | 41° |
Beam Diameter | 7.6m | 11.2m | 15.3m | ||
Frost fresnet | Illuminance | 2638 | 1178 | 668 | 39° |
Beam Diameter | 7.2m | 10.8m | 14.4m | ||
